A salt bath furnace transformer provides low-voltage, high-current power for heat treatment. Output ratings are matched to the bath load, process-temperature control, duty cycle and electrode connections.
Oil free, with strong fire resistance, eliminating the risk of oil leakage; Capable of withstanding short-circuit current and overvoltage, and adapting to harsh environments.
Using environmentally friendly materials, low noise and no pollution, to assist in the construction of a green power grid.
Efficient cooling system ensures that the equipment maintains low temperature during long-term operation, effectively extending the service life of the equipment.
Humanized design, simple operation, convenient and fast daily inspection and maintenance, significantly reducing operating costs.
Durable shell design, impact resistance, corrosion resistance, able to adapt to various complex and harsh working environments.
Modular structure design, supporting quick disassembly and assembly, combined with intelligent monitoring system, making operation and maintenance work more worry free and effortless.
Model number | Rated capacity (KVA) | phase number | Rated voltage (V) | electric current (A) | loss (W) | Impedance voltage % | No load current % | Connection group designation | |||
once | second time | High voltage | Low voltage | no-live load | short circuit | ||||||
| ZUDG(J)-25 | 25 | 1 | 380 | 12.5 14.8 17.4 25 29.6 34.8 | 39.6 48 56.8 79 96 114 | 1250 | 140 | 820 | 8 | 4 | I.io |
| ZUSG(J)-35 | 35 | 3 | 380 | 6.69 8.37 10.45 11.6 14.5 18.1 | 24.6 30.6 38.5 42.7 53.5 66.7 | 1400 | 240 | 1100 | 6 | 6 | Y.D-d-11-12 |
| ZUSG(J)-50 | 50 | 3 | 380 | 11.7 14.7 18 20.4 25.4 31.5 | 43.3 54.5 66.6 75.9 94.5 117 | 1400 | 280 | 1550 | 7 | 5 | Y.D-y-12-11 |
| ZUDG(J)-50 | 50 | 1 | 380 | 11.2 12.7 14.6 17.3 22.4 25.4 29.2 34.6 | 44.2 63.5 76.8 102 132.5 156 173 213.6 | 2315 | 250 | 1450 | 12 | 5 | I.io |
| ZUSG(J)-75 | 75 | 3 | 380 | 11.2 12.6 14.7 17.3 19.3 21.9 25.2 30 | 60 67.5 86.5 102 114 125 142 159.5 | 2190 | 350 | 2000 | 12 | 4 | Y.D-y-12-11 |
| ZUSG(J)-100 | 100 | 3 | 380 | 11.2 12.6 14.7 17.3 19.3 21.9 25.2 30 | 87.5 98.8 114.5 134.5 152 171 197.5 212.5 | 2950 | 450 | 2600 | 12 | 4 | Y.D-y-12-11 |
| ZUSG(J)-150 | 150 | 3 | 380 | 11.2 12.6 14.7 17.3 19.3 21.9 25.2 30 | 129.6 147.8 171.8 202.7 226 250 276 318 | 4460 | 650 | 3500 | 13 | 3 | Y.D-y-12-11 |
| ZUSG(J)-200 | 200 | 3 | 380 | 12.6 15 17.3 19.6 21.8 26 30 34 | 176 209 240 273 304 362 418 462 | 5500 | 820 | 4150 | 12 | 2.5 | Y.D-y-12-11 |
| ZUSJ-250 | 250 | 3 | 380 | 11.5 13.5 15 20 23.5 26 | 218 256 285 380 447 494 | 7200 | 1020 | 5100 | 14 | 2 | Y.D-y-12-11 |
